The technical data …
Here is an overview of the technical data of the Ryzen 7 7700X CPU:
| Manufacturer | AMD |
| Description | Ryzen 7 7700X |
| Model number | 100-100000591WOF |
| Codename | Raphael |
| Architecture | Zen 4 |
| Socket | AM5 |
| Construction | 1 compute DIE @5nm, 1 I/O DIE incl. graphics unit @6nm |
| Number of cores | 8 |
| Number of threads | 16 |
| Base clock rate | 4.5GHz |
| Max. Power clock rate | 5.4GHz |
| Total L1 cache | 512KB |
| Total L2 cache | 8MB |
| Total L3 cache | 32MB |
| Max temp (Tjmax) | 95°C |
| Multiplier | offen |
| PCI Express Version | PCIe 5.0 |
| Standard power consumption / TDP | 105W |
| Memory type | DDR5 |
| Max. Memory clock frequency | 5200MHz |
| max. RAM capacity | 128GB |
| Memory channels | 2 |
| Platform | Desktop |
| Command sets | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Date of publication | September 27, 2022 |
| Special features | Only available without cooler now. AM4 cooler fit if the original AMD backplate is retained. |
These are the technical data of the integrated graphics unit, of the Ryzen 7 7700X CPU:
| Description | AMD Radeon Graphics |
| Architecture | AMD RDNA 2 |
| max. number of displays | 4 |
| max. resolution | 4K @60Hz |
| Interface | HDMI 2.1 @48Gb/s, Display Port 2.0 @UHBR10 |
| Base clock freq | 400MHz |
| max. clock freq. | 2200MHz |
| Memory | 512MB shared RAM |
| API | DX 12.2, OpenGL 4.6 |
| Video Encoder | H.264, H.265 |
| Video Decoder | AV1, VP9, H.265, H.264 |
AMD Ryzen 7 7700X Layout, design and features …
