The technical data laut Manufacturer…
| Manufacturer | NZXT |
| Description | H7 Flow RGB (2024) |
| Dimensions | 544 x 244 x 468mm (LxWxH) |
| Weight | 11.13kg |
| Motherboard support | E-ATX (up to 277mm wide), ATX, Micro-ATX, Mini-ITX |
| Materials | Steel, ultra-clear tempered glass (white), dark tinted tempered glass (black) |
| Number of 5.25″ drives | not possible |
| Number of 3.5″ drives | max. 2 |
| Number of 2.5″ drives | max. 4 |
| CPU cooler height | up to 185 mm |
| GPU length | up to 410 mm |
| PSU length | up to 200 mm |
| Case fan support front | max. 3x 140mm 3x 120mm pre-installed (1 x F360 RGB Core) |
| Case fan support top | max. 3x 120mm or 2x 140mm |
| Case fan support bottom | max. 3x 120mm |
| Case fan support at the rear | max. 1x 120mm or 1x 140mm |
| Connection | 1x 3.5mm headset, 1x USB 3.2 Gen2 Type-C, 2x USB 3.2 Gen1 Type-A |
| Miscellaneous | Tool-free disassembly of the front, sides and top, cable management with 34.5mm space, printed operating instructions included |
Now let’s take a look at the design of the case in detail.
NZXT H7 Flow RGB Layout, design and features exterior …
