The technical data …
| Manufacturer | Seasonic |
| Description | SS-760XP2 |
| Dimensions | 150 mm x 160 mm x 86 mm (WxLxH) |
| Weight | 2700 gramm |
| Color | black |
| Connections | IEC receptacle 2 x Mainboard 5 x 6 pol. SATA/IDE 6 x 8 pol. CPU/PCI-E |
| Cable | 4 x PCI-E 8 pol. 2 x CPU / AUX 8 Pol. 2 x Molex 3 x SATA 1 x Floppy |
| Protection features | OPP, OVP, UVP, OCP, OTP, SCP | Voltages/Currents | 230 V 50-60 Hz 4.5-9.5 A AC +12 V DC 63 A 756 W -12 V DC 0.5 A 6 W +5 VSB 3 A 15 W +5 V 25 A 125 W +3.3 V 25 A 125 W Power 760 W |
| Various | Efficiency 80 Plus Platinum Seasonic S3FC fan control 2 stages Hybrid,Normal 120 mm fan double-ball bearing, lifespan 70.000 hours at 40 °C and 15-65 % rel. humidty full modular lifespan power supply 150.000 hours Test seals cTUVus, TUV, Gost-R, CB , BSMI, CCC, CE, FCC, C-tick Environment seals Energy Star, RoHS, WEEE, ErP Lot 6, REACH 7 years manufacturer guarantee |
Seasonic Platinum 760 W Power Supply Design and Features …
